Shop Star Industries

Root Grapple Buckets

SKU# 170-66

$3,931.00 Was: $4,324.10 Save $393.10

Shipping calculated at checkout.

Option

Heavy Duty 66" Heavy Duty 72" Demolition Grade 72" Demolition Grade 78" Demolition Grade 84"

Please note: this product has a lead time of 2-3 weeks.

Safe & Secure Payments

Move bulky, hard-to-handle materials like brush and logs easily with a Star Industries Root Grapple

The bottom separated tines let dirt sift out when loading large rocks and trash making it the perfect attachment for debris clean up.

Rugged heavy-duty construction for dependability and long life
Built-in covers protect fittings and hyd cylinder
Optional intermediate bottom tines reduce space between tines to approximately 4"
Grease zerks protected with tubes

Root grapple tines curve upward to prevent catching utility lines or cables in storm clean-up
Hydraulic cylinders operate independently to adjust for uneven loads

Root Grapple	Heavy Duty 66”	Heavy Duty 72”	Demolition Grade 72”	Demolition Grade 78”	Demolition Grade 84”
Model	170-66	170-72	170DG-72	170DG-78	170DG-84
Width I.D.	66”	72”	72”	78”	84”
Grapple Capacity	15.8 cuft	17.2 cuft	19.7 cuft	21.84 cuft	20 cuft
Depth	38”	35 ½”	42 ¾”	42 ¾”	42 ¾”
Back Height	21”	21”	21”	21”	21”
Sides	½” Plate	½” Plate	½” Plate	½” Plate	½” Plate
Grapple Thickness	½”	½”	9/16”	9/16”	9/16”
Tine Thickness	½”	½”	½”	½”	½”
Tine Height	3 ½”	3 ½”	5”	5”	5”
Distance between tines	Approx. 8 ½”	Approx. 8 ½”	Approx. 8 ½”	Approx. 8 ½”	Approx. 8 ½”
HD Welded Hyd Cylinders	2” x 10” x 1 ½”	2” x 10” x 1 ½”	2” x 10” x 1 ½”	2” x 10” x 1 ½”	2” x 10” x 1 ½”
Hyd Hoses & Flat Faced Couplers	Included	Included	Included	Included	Included
Empty Weight	725 lbs	750 lbs	950 lbs	943 lbs	967 lbs
