Electric Scissor Aerial Work Platform - Lithium Battery with 394" Lift Height

EKKO ES100E-Li Electric Scissor Lift – 700 lb Capacity, 32.8 ft Platform Height

The EKKO ES100E-Li is a 700 lb capacity electric scissor aerial work platform designed for contractors and trades professionals requiring reliable elevated access in both indoor and outdoor environments. With a maximum platform height of 32.8 ft (394 in) and a maximum working height of 39 ft (472 in), this unit is built for tasks such as mechanical, electrical, and overhead finishing work at significant elevation. Powered by a 25.6 V / 230 Ah lithium battery system and equipped with a Curtis proportional controller, the ES100E-Li delivers precise, controllable lift and drive performance on the job site.

Unlike lead-acid scissor lifts, the ES100E-Li utilizes a lithium battery pack that reduces maintenance demands and supports longer operational cycles between charges. The extendable platform with a 39.37 in extension and a separate 265 lb extension load rating provides added versatility that fixed-deck competitors at this height class typically cannot offer. Compliance with GB25849 and EN280 standards ensures the machine meets recognized safety benchmarks for aerial work platforms.

Technical Specifications

Key Features & Benefits

700 lb Load Capacity with Extendable Platform

The 700 lb platform capacity supports two workers and their tools and materials indoors, reducing the number of trips up and down. The 39.37 in slide-out extension rated at 265 lb allows workers to reach beyond the base platform footprint without repositioning the entire machine, saving time on tasks requiring lateral reach.

Curtis Proportional Controller

The Curtis proportional controller enables smooth, variable-speed control of both lift and drive functions, giving operators precise command over platform movement. This level of control reduces the risk of abrupt starts and stops at elevation, which is critical when working near sensitive overhead structures or fragile finishes.

Lithium Battery Power System (25.6 V / 230 Ah)

The 25.6 V / 230 Ah lithium battery provides substantial energy storage for extended on-site operation without the watering, venting, and acid-spill risks associated with lead-acid alternatives. The onboard 36 A charger allows convenient recharging from standard AC power.

Zero Inside Turning Radius

A minimum inside turning radius of 0 in means the machine can spin in place, making it practical to maneuver in congested work areas such as warehouse interiors, building lobbies, or commercial construction floors where aisle space is limited.

Folding Guardrail for Low-Clearance Entry

The folding guardrail reduces the overall transport height from 96 in to 72 in, allowing the machine to pass through standard doorways and low-clearance building entrances without disassembly. This feature directly reduces setup and transition time between work areas.

30% Gradeability

A 30% gradeability rating allows the ES100E-Li to be driven across inclined surfaces commonly encountered on active construction sites, including loading dock ramps and sloped parking structures. This capability expands where the machine can be deployed without requiring a secondary transport vehicle.

Common Applications

Commercial Interior Overhead Work

The 39 ft working height and zero inside turning radius make the ES100E-Li well suited for HVAC, electrical conduit installation, and ceiling grid work in large commercial interiors such as warehouses, distribution centers, and big-box retail spaces.

Building Maintenance and Facility Services

Facility maintenance teams can use the ES100E-Li for lighting replacement, ductwork inspection, and structural painting at heights up to 39 ft, with the extendable platform providing additional reach between repositioning moves.

Construction Finishing Trades

Drywall finishing, painting, and mechanical rough-in work at elevation benefit from the stable 88.58 in x 45.27 in platform that accommodates two workers indoors with tools and materials on a single lift.

Outdoor Maintenance and Installation

Rated for one worker outdoors in wind speeds up to 12.5 m/s, the ES100E-Li can be used for facade work, signage installation, and exterior lighting in exposed conditions where indoor-only machines cannot operate.

Compatible Materials / Surface Types

• Concrete floors (indoor and outdoor)
• Asphalt surfaces
• Compacted aggregate and graded surfaces (within tilt angle limits)
• Inclined surfaces up to 30% grade
• Surfaces within 3° front tilt / 1.5° lateral tilt tolerance

Frequently Asked Questions

Q: How many workers can operate on the platform at one time?
A: The ES100E-Li is rated for a maximum of 2 workers indoors and 1 worker outdoors, subject to the platform load capacity of 700 lb and the extended platform rating of 265 lb.

Q: What is the maximum allowable wind speed for outdoor use?
A: The machine is rated for outdoor operation in wind speeds up to 12.5 m/s. Indoor use requires no wind exposure (0 m/s rated wind condition applies).

Q: What compliance standards does the ES100E-Li meet?
A: The ES100E-Li complies with GB25849 and EN280 standards for aerial work platforms.

Q: Can the machine be driven while the platform is elevated?
A: Yes. Drive speed while elevated is limited to 0–0.8 km/h, compared to 0–3.2 km/h in the folded/stowed position, providing a controlled slow-travel mode at height.

Q: What is the overall transport height with the guardrail folded?
A: With the guardrail folded, the overall height is 72 in, enabling passage through standard doorways and low-clearance entry points.

Q: What warranty is included?
A: The ES100E-Li is covered by a 3 Years Limited Warranty.
