Bartell Global's HD series dust extractors feature a two-stage filtering system with jet-pulse filter cleaning. Remove up to 99.97% of dangerous airborne particulates to keep your operators safe and your business compliant with environmental regulations. With two separate motors with individual switches, the airflow/suction can be adjusted for different applications as needed.
- Equipped with 2 HEPA filters which remove at least 99.97% of airborne particles down to 0.3 micrometers in diameter securing a high standard of quality and safety
- 2 individual motor switches provide variable suction strength and power
- Reverse-air jet-pulse filter cleaning system effectively cleans and removes dust build-up on the filters.
- Easy to use inlet closure eliminates the need to remove hoses when pulsing and cleaning filters
- Easily connects to hand-operated power tools to extract concrete dust while cutting and grinding
- Equipped with a continuous-bag system for safe & easy disposal of concrete dust
- Comes with 25ft hose and floor wand
Technical Specs
| Models | HD2 |
|---|---|
| Volts | 120 |
| Amps | 16 |
| Inlet Diameter | 2.5" (63mm) |
| Power (hp) | 3.2hp |
| Air Flow (cfm) | 240 |
| Water lift (inches) | 100 |
| Pre-filter (F8) >99.5% @1.0um | 34 ft2 (3m2) |
| HEPA Filter (H13) >99.99% @0.3um | 26 ft2 |
| Length | 26" (65cm) |
| Width | 23" (58cm) |
| Height | 50" (126cm) |
| Weight | 119 lbs (54kg) |
