Vertical movement produces even pressure resulting in precise punching and shearing with minimal distortion that results in extended tooling life

Product Features

  • Two Available Workstations
  • 9 interchangeable Attachments available to tailor the Ironworker to your needs
  • 7 optional Accessories available to increase precision and efficiency
  • Requires an Edwards Ironworker with PowerLink System or a Portable Power Unit to operate
  • Optimized workstation heights for improved efficiency
  • Electric foot pedal with integrate jog control
  • 20’ quick-connect hose for simple “plug & play” operation
  • ANSI B11.5-1988(02) Compliant Guarding
  • Durable, heavy-duty, Made In USA steel construction
  • Vertical movement produces even pressure resulting in precise punching and shearing with minimal distortion that results in extended tooling life
  • Punches are easily changeable, long-lasting and available from 1/8" to 4" diameters with square, oblong, hex, metric, and custom shapes

PUNCH

Rating (tons) 25

Max Capacity (in.) 1 diam. in 5/16 mild steel

Work Height (in.) 36-3/4

Throat Depth (in.) 5-1/2

Stroke (in.) 1

OPEN STATION

Throat Depth (in.) 5-1/2

Work Height (in.) 34-3/4

GENERAL SPECIFICATIONS

Product Dimensions (.in) 25 x 34-1/2 x 51

Weight (lbs.) 836

Country of Manufacture USA

Warranty 1 Year Parts
