Skid Steer Power Rakes

SKU# 132110

$12,531.00

Shipping calculated at checkout.

Safe & Secure Payments

Flexible financing available

Discover your options →

Centra Funding

Orders $10,000+

Apply Now

PEAC Solutions

Orders $3,000+

Apply Now

With machine sizes increasing in the industry, there is a need for a more powerful and durable power rake / soil conditioner attachment.

The Blue Diamond® Extreme Duty Power Rake is designed to power through jobs where others fail, and is set up for simple servicing. The massive 6,000 series motor and optimal drum size produce maximum torque, and the motor is kept out of the way, maximizing usable width in tighter areas. Aggressive 2″ teeth are ideal for leaving a fresh seed bed with fewer passes. Our rental customers are finding this unit rents more often, is asked for by name, and the customers love the increased productivity over all other brands! Rental Recommended.

*Over 3,000 PSI requires a case drain.

NOTE: These are shown with OPTIONAL Skid shoes and harden steel or carbide teeth that are either replaceable or fixed.

Features

6,000 series motor weighs twice what competitive models do, and has around 40% more torque
4” x 4″ square tube frame
18 – 26 GPM hydraulic flow, max 4000 PSI
Optional replaceable teeth versus fixed teeth that require welding to replace
1.5” spindle on castors with spacers versus friction adjusters that work loose
Airless tires – no flats
1” front wheel axles versus competitive ¾”
1.5” motor shaft and high pressure seals
5 position, 20 degree angle, manual or hydraulic
Optional bolt-on skid shoes add 30% load capacity over side plates alone
6 3/4” drum diameter, 10 3/4” including teeth
Replaceable teeth hardness is HRC 50
Double struts on the castors

PART NUMBER	TEETH	WORKING WIDTH (STRAIGHT)	WORKING WIDTH (ANGLED)	OVERALL WORKING WIDTH (STRAIGHT)	WEIGHT
132110	Replaceable	72″	66″	82″	1,135 lbs
132112	Fixed	72″	66″	82″	1,085 lbs
132115	Replaceable	84″	78″	78″	1,160 lbs
132117	Fixed	84″	78″	94″	1,110 lbs
132120	Replaceable	96″	90″	106″	1,185 lbs
132122	Fixed	96″	90″	106″	1,135 lbs

EXTREME DUTY POWER RAKE MANUAL

EXTREME DUTY POWER RAKE
