| Model | HRC 800 VS | HRC 800 bimotor |
|---|---|---|
| Motor | 10 HP | 15+5 HP |
| Drive Inverter | - | - |
| Volt | 380-480 | 380-480 |
| Hertz | 50/60 | 50/60 |
| Amp | 32 | 32 |
| Tool Speed | 400-1300 rpm | 400-1300 rpm |
| Work Diameter | 800mm | 800mm |
| Tool Size | 4x240mm | 4x240mm |
| Water Tank | 46 lt | 46 lt |
| Size LxAxP cm | 214x130x86 | 214x130x86 |
| Weight | 385 Kg | 430 Kg |
| ESTIMATED PRODUCTION | |
|---|---|
| Concrete Polishing 7 step | 25-30 m2/h |
| Concrete Grinding 1 step | 100-130 m2/h |
| Terrazzo Polishing 5 step | 25-30 m2/h |
| Resin Removal 1 step | 100-150 m2/h |
| Paint Removal 1 step | 100-150 m2/h |
| Marble Polishing 5 step | 10-15 m2/h |
| Granite Polishing 7 step | 6-10 m2/h |
Data may vary depending on surface conditions, tools used, operator convenience, equipment, etc.
| Model | HRC 800 |
|---|---|
| Volume | 1.80 m3 |
| Size | 150x145x85 cm |
| Weight | 450 kg |
