Cat 1000 Expert Hard Materials 15mm segment height designed for cutting hard concrete, reinforced concrete, concrete, slabs, pavers, and hard stone.

Cat® Hard Material blades are designed for intensive use across the 3 performance grades:

Good - 10mm (600 Pro)

Better - 12mm (800 Pro)

Best - 15mm (1000 Pro)

Reinforced ConcreteHard ConcreteConcrete Slabs
Concrete BlocksPaving BricksHard Stone

Each individual product has specifically designed segments shape and geometry which complements the diamond grit and bond formulation that is proved to enhance the cutting performance in terms of fluidity and smoothness of cut, speed and blade life. Cat® Hard Material blades are able to cut a multitude of hard materials and easily cut through the hardest aggregates and applications. Each increase in performance rating increases the performance in terms of speed and life by use of higher diamond quality and diamond concentration, bond formulation and segment height.

ATTRIBUTES

  • Ultimate Diamond Quality & Bond Formulation
  • Ultimate Life & Speed Of Cut
  • Fully Hardened & Heat Treated Steel Core
  • Vented Cooling Holes For Rapid Heat Dispersion
  • 2X Laser Welded For Safety & Stability Of Segments
  • Unique Turbo Segment Design For Aggressive Cutting Action
  • Unique V Turbo Design Clears Abrasive Fines From The Cut & Generates Less Friction
  • Keyhole Gullet Design For Dust Extraction From Cut

APPLICATION

Heavily Steel Reinforced Concrete, Critically Hard Aggregate Concrete (Flint, Chert), Hard To Medium Aggregate Concrete (Chert - Trap Rock - River Gravel), Medium Aggregate Concrete (Traprock - Quartz), Soft - Medium Aggregate Concrete (Granite - Limestone), Class A Engineering Brick 125 N/Mm2, Clay Pipe - Roof Tiles, Clay Paviours, Quarry Tiles, Terracotta, Porphyry, Class B Engineering Brick 75N/Mm2, Light Reinforced Concrete, Basalt, Hard Limestone, Limestone Aggregate Concrete, Lightly Reinforced Concrete, Concrete Paviours - Kerbs - Slabs, Concrete Roof Tiles - Pipes, Hard Facing Brick, Medium Facing Brick.

Ductile Iron, Quartzite, Refractory Brick, Soft Facing Bricks, Concrete Blocks Over 15N/Mm2, Hard Slate, Soft Slate, Marble, Concrete Screed.

Soft Sandstone (Coarse Grit), Plaster - Grout, Concrete Block Under 15N/Mm2, Thermal Block 7 N/Mm2.

Key

★★★★

Correct Bond For Application Optimal Performance, Speed & Life

★★★

Good Match Bond For Application Excellent Performance Speed & Life

★★

Acceptable Bond For Application Reduced Performance, Speed & Life

Occasional Use Only - Much Reduced Performance, Speed & Short Life - Glazing & Premature Wear Will Occur



  • PRODUCT TYPE DIAMETER SEGMENT HEIGHT SEGMENT WIDTH MAIN ARBOR - BORE REDUCING RINGS INCLUDED MACHINES USED
    SEE KEY
    PART NO CODE NO MM INCH MM INCH MM INCH MM INCH MM INCH
    DA35610U USAHM101215 300 12 15 0.591 3.175 0.125 25.4+P 1+P 20MM 0.78 High Speed SawFloor SawLow HP Walk-BehindTable SawBrick Saw
    DA35611U USAHM101415 350 14 15 0.591 3.175 0.125 25.4+P 1+P 20MM 0.78 High Speed SawFloor SawLow HP Walk-BehindTable SawBrick Saw
    DA35612U USAHM101615 400 16 15 0.591 3.175 0.125 25.4+P 1+P 20MM 0.78 High Speed SawFloor SawLow HP Walk-BehindTable SawBrick Saw
    DA35613U USAHM101815 450 18 15 0.591 3.175 0.125 25.4+P 1+P 20MM 0.78 High Speed SawFloor SawLow HP Walk-BehindTable SawBrick Saw
  • Available in USA, non-oSa accredited.
