Manual Tilter 300 - MT4 Lifter Series

Manual Tilter 300 MT4 — Intelli-Grip® Technology

With quick attach and release, these lifters enable ergonomic handling of heavy loads by a single operator.

Equipped with Intelli-Grip Technology®, automatically monitoring vacuum and power systems to maximize safety and efficiency while simplifying maintenance and repairs.

Models: MT48LAC3 & MT48LDC3

This compact 4-pad lifter is available in an AC-powered model for use in production settings and a DC-powered model for window installations.

Intelli-Grip® Technology

This WPG-exclusive technology oversees power and vacuum systems, increasing productivity and improving safety. Download the Intelli-Grip® App to monitor the lifter from a distance!

Dual Vacuum System

Handle loads with the added safeguard of two independent air-line circuits!

Flat and Vertical Tilt-Lockout

A simple knob allows operators to change the pad-frame orientation from flat to upright and back again with ease, saving time and energy!

Specifications

Standard Features

• Intelli-Grip® Technology — Available exclusively from Powr-Grip®! Actively monitors power and vacuum systems to increase safety and productivity, using LCD-screen messages, diagnostic codes and other features. (AC & DC)
• Dual Vacuum System — Features two independent air-line circuits to reduce risk of workplace accidents. (AC & DC)
• Battery and Charger — Provide independent, rechargeable power source for cord-free lifter operation in any location; on-board charger features status indicator and automatic shut-off. (DC only)
• Battery Gauge — Shows energy level in real time, to help determine when charging is needed. (DC only)
• Notification Buzzer and Strobe Light — Alert operator of problems with power or vacuum system, with various patterns of sound and light to indicate severity; backup battery provides independent power for buzzer. (AC & DC)
• Green Lift Light — Provides visual assurance to know when vacuum is sufficient for lifting. (AC & DC)
• Vacuum Gauges — Feature green and red zones to clearly indicate whether vacuum levels are sufficient for lifting. (AC & DC)
• Vacuum Line Filters — Protect the vacuum generating system from contaminants. (AC & DC)
• Twist-Lock Electrical Plug — Provides a secure connection to the AC power source, to prevent accidental disconnection. (AC only)
• Two-Action Blow-Off Release — Uses two separate buttons to avoid accidental release, and reverses airflow to quickly separate vacuum pads from loads, without after-stick. (AC & DC)

Available Options

• Alternative Pad Compounds — Specially designed for heat resistance, marking resistance, coated surfaces and other purposes. (AC & DC)

Design Standards

• ASME B30.20 (BTH-1 Design Category "B", Service Class "0"): Industry standards established by the American Society of Mechanical Engineers (ASME) and published by the American National Standards Institute (ANSI).
• CE/UKCA: Regulatory standards for health and safety required in the European Union and the United Kingdom.
