Smith FS150 Electric Handheld Rotary Scarifier
The Smith FS150 Electric Handheld Rotary Scarifier is a rugged, lightweight rotary surface preparation tool engineered for heavy-duty concrete and asphalt applications. Designed for contractors and serious DIY users, it quickly scabbles, textures, abrades, descales, keys, cleans, smooths, and removes surface coatings with precision.
With a removal path up to 7 inches wide, the FS150 accepts multiple cutter drum configurations to achieve the exact surface profile required. An integrated vacuum port allows connection to a dust collection system for cleaner, safer operation.
Applications
The Smith FS150 is ideal for:
- Surface preparation
- Concrete scarifying
- Asphalt scarifying
- Coating removal
- Paint and line stripe removal
- Surface cleaning
- Scabbling
- Texturing
- Abrading
- Descaling
- Surface keying
- Concrete smoothing
- Surface reduction
- Touch-up work
- Polishing
- General surface restoration
Standard Features
- Lightweight handheld design
- Ergonomic vibration-dampening handle
- Built-in vacuum port for dust collection
- Heavy-duty construction
- Multiple cutter drum options
- Ideal for concrete and asphalt surfaces
Power Options
| Model |
Motor |
|
2016207
|
1.3 HP, 120V Electric (220V Optional) |
Performance
| Specification |
Value |
| Maximum Cutting Width |
Up to 7 in. |
| Maximum Depth per Pass |
1/16 in. |
| Production Rate |
Up to 100 sq. ft. per hour |
Cutter Options
Choose the cutter that best matches your application:
- Tungsten Carbide Flails
- Steel Finish Cutters
- Tungsten Carbide Scraping Cutters
Custom cutter patterns and cutting widths from 2" to 8" are also available.
Specifications
| UPC PRODUCT |
00769946783445 |
| DIVISION |
CED |
| FAMILY CODE |
FAMSTH |
| UNIT OF MEASURE |
EA |
| HEIGHT |
22 IN | 55.88 CM
|
| LENGTH |
22.25 IN | 56.515 CM
|
| WIDTH |
22.25 IN | 56.515 CM
|
| VOLUME |
6.294 FT3 | .178 M3
|
| SHIPPING WEIGHT |
19 LBS | 8.62 KG
|
Available Manuals
- FS150 Data Sheet
- Cutter Drum Assemblies Guide
- FS150 Operation & Parts Manual
Surface Profile (SP1–SP10)
The Smith FS150 can produce a wide range of concrete and asphalt surface profiles depending on the cutter configuration and operating technique.
Surface Profile (SP) classifications range from:
-
SP1 – Nearly flat surface
-
SP10 – Extremely rough surface
Selecting the proper surface profile ensures proper adhesion for coatings, overlays, waterproofing systems, repair mortars, and flooring installations.
