Quadra-Tilt 360 8 Pads Lifter - (MTA) Medium Duty Lifter Series
SKU# 97450AM
Couldn't load pickup availability
Safe & Secure Payments.
Finance this today with .png)
Apply Here
Quadra-Tilt 360 8 Pads Lifter - (MTA) Medium Duty Lifter Series
QUADRA-TILT 360 (AC) 120 V 8 Pad Vacuum Lifter for safely moving and tilting stone
Made When Ordered
Holes and defects in the load can easily be avoided by repositioning the vacuum pads on this Powr-Grip® vacuum lifter with our innovative Quadra-Tilt linkage.
The Quadra-Tilt Vacuum Lifters feature an innovative four-bar tilt mechanism that significantly reduces the effort of tilting loads between flat and upright positions. This tilt mechanism also reduces hazards associated with lifting loads from upright racks: When a load is tilted to either the upright or the flat position, the vacuum lifter maintains the load position automatically without using latches, eliminating the tendency for a load to "kick back" at the operator's knees.
The MTA8LP6FAC vacuum lifter also features sliding adjustable vacuum pads that accommodate a variety of load sizes and shapes. Holes or defects in the load surface are easily avoided because vacuum pads can attach at any number of locations on the load.
Adjustable Pad Spread:
Length: Min: 38" [962 mm], Max: 100-3/4" [2556 mm]
Width: 29" [737 mm]
Number / Size of Vacuum Pads:
8 / 6" [15 cm] diameter pads
Maximum Load Capacity:
360 lbs [165 kg]
Weight of Lifter:
110 lbs [50 kg]
Standard Operating Power:
120 volts AC, 60 hertz, 3 amps
Apply / Release Times:
2 seconds / 2 seconds (approx)
Load Movement:
Assisted manual tilt, 90° between upright and flat
Standard Features:
Vacuum gauge
Vacuum line filter
Sliding adjustable vacuum pad mounts
Spring-mounted vacuum pads
Twist-lock electrical plug
Multiple handles for easy load positioning
Blow-off for quick release
| Load Capacity | 360 lbs [165 kg] |
| Per-Pad Capacity | 50 lbs [23 kg] |
| Pad Model | LP6F |
| AC Power | Standard |
| AC Volts | 120 VAC |
| AC Amps | 3 |
| Hertz | 50/60 |
| Phase | 1 |
| Apply Time (AC) | 2 Seconds |
| Release Time (AC) | 2 Seconds |
| Weight (AC) | 110 lbs |
| Manipulation | Continuous |
| Tilt | 90° |
| Tilt Power | Assisted Manual |
| Max Pad Spread (L) | 100.75" |
| Min Pad Spread (L) | 38" |
| Max Pad Spread (W) | 29" |
| Min Pad Spread (W) | 29" |
| Max Height | 43" |
| Min Ambient Temp | 32° F |
| Min Load Temp | 32° F |
| Max Ambient Temp | 100° F |
| Max Load Temp | 100° F |
| Stock# | Model# | Description | Load Capacity | Power |
|---|---|---|---|---|
| 97450AM | MTA8LP6FAC |
Lifter with wide pad spread. 120v power system. |
360 lbs [165 kg] | AC |
| 97450 | MTA8LP6FAC |
Lifter with narrow pad spread. 120v power system. |
360 lbs [165 kg] | AC |
| 97452AM | MTA8LP6FAC |
Lifter with narrow pad spread. 240v power system. |
360 lbs [165 kg] | AC |
| 97452 | MTA8LP6FAC |
Lifter with narrow pad spread. 240v power system. |
360 lbs [165 kg] | AC |
| 97451AM | MTA8LP6FAIR |
Lifter with wide pad spread. |
360 lbs [165 kg] | Air |
| 97451 | MTA8LP6FAIR | Lifter with wide pad spread. | 360 lbs [165 kg] | Air |
| MTA8LP6FDCS(W) | MTA8LP6FDCS |
SPECIAL ORDER:
Mobile, battery-powered lifter with wide pad spread. |
360 lbs [165 kg] | DC |
| MTA8LP6FDCS(N) | MTA8LP6FDCS |
SPECIAL ORDER:
Mobile, battery-powered lifter with wide pad spread. |
360 lbs [165 kg] | DC |
