Wood's Powr-Grip Channel Lifter - P1 Compact Lifter Series
SKU# 98713
Couldn't load pickup availability
Safe & Secure Payments.
Finance this today with .png)
Apply Here
Wood's Powr-Grip Channel Lifter - P1 Compact Lifter Series
Wood's Powr-Grip Channel Lifter - P1 Compact Lifter Series Ideal for glass and slightly heavier loads, polished stone & other more demanding surfaces, insulated metal panels or other cladding, and convex surfaces.
Employing state-of-the-art technology, Intelli-Grip®automatically monitors vacuum and power systems to:
• Maximize productivity
• Help reduce human error
• Simplify maintenance and repairs
• Protect employees and property from harm
| Stock# | Model# | Description | Load Capacity | Power |
|---|---|---|---|---|
| 98714__ | P11216L02DC3 |
INTERNATIONAL VOLTAGES:
98714CEDE- 240v charger (German) |
300 lbs [135 kg] | DC |
| 98713 | P11102DC3 |
Flat and smooth surfaces lifter with Intelli-Grip and dual vacuum system. Ideal for glass and slightly heavier loads. (!) EU Law requires a secondary safety device when used on construction sites. |
350 lbs [160 kg] | DC |
| 98710 | P1HV1102DC3 |
Flat and slightly textured surfaces lifter with Intelli-Grip and dual vacuum system. Ideal for polished stone & other more demanding surfaces. (!) EU Law requires a secondary safety device when used on construction sites. |
300 lbs [135 kg] | DC |
| 98712 | P110T02DC3 |
Flat and textured surfaces lifter with Intelli-Grip and dual vacuum system. Ideal for insulated metal panels or other cladding. (!) EU Law requires a secondary safety device when used on construction sites. |
300 lbs [135 kg] | DC |
| 98711 | P110C02DC3 |
Curved and smooth surfaces lifter with Intelli-Grip and dual vacuum system. Ideal for concave or convex surfaces. (!) EU Law requires a secondary safety device when used on construction sites. |
300 lbs [135 kg] | DC |
|
Maximum Load Capacity |
300 lbs [135 kg]* |
|
Intelli-Grip®Technology |
Automatic self-testing ensures lifter is ready for use, every lift. Color display provides critically relevant information at a glance. Anticipates threats and alerts operator beforehand with clearly visible and audible warnings. Continuously monitors battery and prevents lifter from attaching to loads if energy is hazardously low. |
|
Load Movement |
Manual rotation, 180° edgewise, with locking in three positions.Manual tilt, 90° between upright and flat, with automatic latchingin upright position (in center rotation position, as shown on drawings). |
|
Standard Operating Power |
12 volts DC, 5 amps |
|
Standard Features |
Intelli-Grip® Technology Adjustable-position lift spool Dual vacuum system On-board battery and charger Battery energy gauge Vacuum gauges Vacuum line filters |
|
Available Options |
Remote control system (59906) 9" [23 cm] diameter pad (VPFS9) Alternative pad compounds for low-marking, temperature resistant and coated surface applications (special order) |
|
Dual Vacuum System |
Features two completely independent vacuum circuits. Provides vacuum system redundancy. Limits possibility of a catastrophic failure. Reduces chance of harm to personnel or equipment. |
|
Lifter Weight |
80 lbs [36 kg] |
|
Standard Pad Spread |
24" x 11" [61 cm x 28 cm]
|
|
Number / Size of Pads |
2 / 10" [25 cm] dia. lipped vacuum pads |
|
Design Standards |
ASME B30.20 (BTH-1 Design Category "B", Service Class "0") AS 4991-2004 |
