Brave Hi-Pressure Pump

The Brave 2-in. commercial-grade high-pressure pump is ideal for moving large amounts of clean water. This heavy-duty unit is typically used for irrigation making it perfect for farmers. The commercial-grade pump moves liquids faster so you can get the job done quickly. Hose kits are available.

Features and Benefits

  • Aluminum closed impeller and cast iron volute-die cast aluminum pump
  • Used for fire protection and irrigation
  • Large pump casing increases capacity
  • Built-in check valve for fast priming
  • Removable/replaceable cast iron suction and discharge flanges
  • Discharge port rotates in 90 degrees increments
  • EPDM/EPR seal with carbon and ceramic faces with optional Viton seals and elastomers
  • One tool serviceability, tool included
  • Includes strainer and rubber foot mounting
  • Max temperature of 180F
  • 215-ft. total head lift, 66-ft. total suction head
  • Optional wheel kit available

Product Specifications

Equipment Type Pump
Discharge Capacity 120 Gal/min
Discharge Port Diameter 2 In. Npt
Displacement 196cc
Dry Weight 95 Lbs
Engine Gx200
Engine Brand Honda
Impeller Cast Iron
Mechanical Seal (Pump Case/Impeller) Epdm / Epr Seal With Carbon And Ceramic Faces With Optional Viton® Seals And Elastomers
Pressure 93 Psi Max
Pump Type High Pressure
Suction Head Lift 66 Ft.
Suction Port Diameter 2 In. Npt
Total Head Lift 215 Ft.
