Features:
- 1 3/4" hardened steel paddle shaft, with double bearings and eight grease seals!
- Tapered drum opening eliminates spilling on the job.
- Heavy duty safety cage with oversized bag breaker.
- Removable heavy duty hitch.
- 14 gauge steel laser cut shroud with triple roll pin hinges.
*Electric motor options also available
Technical Specs of Concrete Mixing
80 lb redi-mix
1.5-2
Capacity (cu ft)
6
Engine
Honda GX160
Fuel Capacity
3.3 qts
Width in (cm)
51" (129 cm)
Length in (cm)
76" (193 cm)
Height in (cm)
58" (147 cm)
Weight (dry)
737 lbs (335 kg)
Sound Power
105 Dba
Drum Material
Steel
|
Specifications |
||||||
|
Model |
MM6PH160 |
MM6H160 |
MM8PH240 |
MM8H240 |
MM9H240 |
MM12H390 |
|
Capacity (bag) |
1.5 - 2 |
1.5 - 2 |
2 - 2.5 |
2 - 2.5 |
2.5 - 3 |
2.5 - 3 |
|
Capacity |
6ft3 (0.17m3) |
6ft3 (0.17m3) |
8ft3 (0.23m3) |
8ft3 (0.23m3) |
9ft3 (0.25m3) |
12ft3 (0.34m3) |
|
Engine |
Honda GX160 |
Honda GX160 |
Honda GX240 |
Honda GX240 |
Honda GX240 |
Honda GX390 |
|
Fuel Capacity |
3.3qts (3.1L) |
3.3qts (3.1L) |
5.6qts (5.3L) |
5.6qts (5.3L) |
5.6qts (5.3L) |
6.4qts (6.1L) |
|
Machine Dimensions |
||||||
|
Length Width Height Weight (dry) |
76" (193cm) |
76" (193cm) |
76" (193cm) |
76" (193cm) |
76" (193cm) |
76" (193cm) |
|
51" (129cm) |
51" (129cm) |
51" (129cm) |
51" (129cm) |
51" (129cm) |
51" (129cm) |
|
|
58" (147cm) |
58" (147cm) |
59" (150cm) |
59" (150cm) |
59" (150cm) |
60" (152cm) |
|
|
737lbs (335) |
737lbs (335) |
860lbs (395) |
860lbs (395) |
870lbs (395) |
880lbs (400) |
|
|
Sound Power |
105Dba |
105Dba |
105Dba |
105Dba |
105Dba |
105Dba |
|
Drum Material |
Poly |
Steel |
Poly |
Steel |
Steel |
Steel |
