Caldwell Model 86 Double-Leg Coil Lifter

Caldwell Model 86 Double-Leg Coil Lifter

The Caldwell Model 86 Double-Leg Coil Lifter is a versatile, economical two-sided coil lifting solution designed for safely handling steel coils in facilities where aisle space is limited. Featuring a newly redesigned hook profile, adjustable hook spacing, and high-tensile alloy steel construction, the Model 86 offers an affordable way to lift a wide variety of coil widths while reducing the need for multiple dedicated lifting devices.

Its narrow, thicker hook design allows operators to work in tighter storage areas, while rounded hook shoes slide smoothly over the outside diameter of the coil to help reduce product damage. Extra-long adjustment pins with integrated hand guards simplify width adjustments while minimizing pinch-point hazards. The Model 86 is available in capacities from 10 to 40 tons and complies with applicable ASME standards for below-the-hook lifting equipment.

Features

Budget-Friendly Two-Sided Coil Lifter

• Most economical two-sided Caldwell coil lifter
• Excellent value for industrial applications
• Handles multiple coil widths
• Reduces equipment costs
• Simple mechanical design
• Low maintenance

New Narrow Hook Design

• Narrower hook profile
• Increased hook thickness
• Fits into tighter aisle spaces
• Easier access to closely stacked coils
• Improved strength
• Better maneuverability

Rounded Hook Shoes

• Rounded shoe corners
• Slides smoothly over coil exterior
• Helps prevent scratching
• Reduces coil damage
• Easier engagement
• Improved material protection

Adjustable Hook Width

• Easily adjusts for different coil widths
• One lifter handles multiple applications
• Quick mechanical adjustment
• Improved versatility
• Reduces equipment inventory
• Efficient setup

Extra-Long Link Pins with Hand Guards

• Long adjustment pins
• Integrated hand guards
• Reduced pinch points
• Safer adjustments
• Faster setup
• Improved operator safety

High-Tensile Alloy Steel Hooks

• Manufactured from alloy steel
• High-strength construction
• Excellent durability
• Heavy-duty industrial use
• Long service life
• Reliable lifting performance

Optimized Bail Design

• Engineered for DIN crane hooks
• Compatible with U.S.-style crane hooks
• Improved hook engagement
• Better lifting stability
• Modernized design

ASME Compliant

• Designed to applicable ASME standards
• Below-the-hook lifting device
• Industrial safety design
• Commercial-duty construction

Benefits

• Ideal for narrow aisles
• One lifter accommodates multiple coil widths
• Lower cost than powered models
• Reduces coil surface damage
• Quick width adjustments
• Improved operator safety
• Heavy-duty alloy steel construction
• Long equipment life
• Excellent for steel service centers

Technical Specifications

Available Models

Standard Equipment

• Adjustable double-leg design
• High-tensile alloy steel hooks
• Rounded hook shoes
• Extra-long adjustment link pins
• Hand guards
• Optimized bail
• Heavy-duty welded construction
• Industrial finish

Ideal Applications

• Steel service centers
• Steel mills
• Coil warehouses
• Manufacturing plants
• Metal fabrication
• Roll forming operations
• Slitting operations
• Distribution centers
• Heavy industrial facilities
• Material handling

Industries Served

• Steel processing
• Automotive manufacturing
• Metal fabrication
• Manufacturing
• Warehousing
• Distribution
• Heavy equipment
• Industrial processing
• Construction materials
• Primary metals

Advantages of the Model 86

Safety Information

• Never exceed the rated lifting capacity.
• Adjust both hooks evenly before lifting.
• Verify the hooks are fully engaged before raising the load.
• Inspect hooks, pins, hand guards, and bail before each use.
• Ensure the crane hook is centered over the load.
• Follow OSHA and ASME lifting requirements.
• Never lift personnel.

Frequently Asked Questions

What is the Caldwell Model 86 used for?

The Model 86 is a manually adjustable double-leg coil lifter designed for safely lifting and transporting steel coils in facilities with limited aisle space.

What capacities are available?

The Model 86 is available in 10, 15, 20, 25, 30, and 40-ton capacities.

What coil widths can it accommodate?

Depending on the model, it accommodates coil widths from 18 inches up to 76 inches.

What makes the new hook design better?

The redesigned hook is narrower and thicker, allowing it to fit into tighter storage areas while maintaining strength. Rounded hook shoes also help prevent damage when sliding over the outside of the coil.

How does the Model 86 improve operator safety?

Extra-long adjustment pins with integrated hand guards reduce pinch points during hook-width adjustments, making setup safer and easier.

Does the Model 86 comply with industry standards?

Yes. The Caldwell Model 86 is designed to comply with applicable ASME standards for below-the-hook lifting devices.
