Paving Stone Lifter

General

When installing paving flags, the Paving Stone Lifter saves time and reduces stress on the back and knees. It can also be used with concrete, sandstone, slate, etc. The safe lifting height recommended when using the Paving Stone Lifter is no more than 75mm (3”) to 125mm (5”) above the work area.

Feature

• The Head is constructed with heavy-duty aluminum.
• A complete line of interchangeable heads is available in different sizes for lifting various types and sizes of materials.
• Visual low vacuum alert.

Specifications

	Metric	Imperial
The size of the suction plates	200x200 mm: 60kg 260x260 mm: 120kg	8"x8": 132 lb 10"x10":264 lb
Width of handles	600 mm	23.6"
Net weight	19 kg	42 lb
Gross weight	34 kg	75 lb
Packaging dimensions	L.720xW.420xH.590 mm	28"x17"x23"

• Battery information for the device

Battery capacity	12V-7A
Charger battery	12V-2A
Charging time	3.5 hours
Non-stop working time	>3 hours
6-month warranty	-

• Motor information

Vacuum flow rate	32.5 liters/minute
Motor	12V DC-4A
