Order Picker - 216" Lift · Lithium

EOP150 Series Lithium Order Picker – 1,500 lb Capacity with Up to 275" Lift Height

The EOP150 Series Lithium Order Picker is a standing-operation, electric-powered material handling machine engineered for efficient order picking in racking systems, warehouses, manufacturing floors, and storage facilities. Available in three lift height configurations — 165", 216", and 275" — this unit serves contractors and operations professionals requiring reliable, high-reach picking capability. Built with high-quality steel and durable components, the EOP150 is designed to withstand heavy usage, impacts, and frequent directional changes across demanding industrial environments.

Unlike lead-acid alternatives, the EOP150 Series runs on a 24V/200Ah lithium battery with hoist-lift battery replacement, reducing downtime and maintenance overhead. The Curtis® controller paired with an AC drive motor and Electronic Power Steering (EPS) delivers precise, consistent performance that lead-acid or DC-drive machines cannot match at this weight class.

Technical Specifications

Key Features & Benefits

24V / 200Ah Lithium Battery

Lithium battery technology provides longer run times and faster charging cycles compared to lead-acid alternatives, reducing unplanned downtime on active warehouse floors. The hoist-lift battery replacement method allows for efficient swap-outs when extended multi-shift operations require it.

Electronic Power Steering (EPS)

EPS reduces operator fatigue during long picking shifts by delivering precise, responsive steering without the physical effort required by mechanical systems. In tight aisle environments — such as those requiring only 114" of aisle width — this precision directly improves throughput and safety.

Curtis® Controller with AC Drive Motor

The industry-recognized Curtis® controller manages motor performance with accuracy and reliability, supporting four configurable travel speed gears from 0.37 mph to 3.10 mph. The AC drive motor delivers consistent torque and requires less maintenance than DC brush-type motors.

Three Lift Height Configurations

With lift heights of 165", 216", and 275", the EOP150 Series can be matched to the specific racking height of a given facility rather than over- or under-specifying. This flexibility makes it suitable across a wide range of storage rack configurations found in warehouses and manufacturing environments.

Polyurethane Drive and Load Wheels

Polyurethane wheels provide low rolling resistance, extended wear life, and floor protection compared to harder wheel compounds. They are well-suited for the smooth concrete floors common in warehouse, distribution, and manufacturing settings.

Ergonomic Handle, Controls, and Auxiliary Fork

The ergonomic handle at 46" height and operator-focused control layout reduce strain during repetitive picking operations. The auxiliary fork expands the machine's ability to handle varied load configurations encountered in multi-SKU picking environments.

Common Applications

Warehouse Order Picking

The EOP150 is purpose-built for picking individual or case-level items from elevated racking in warehouse environments, where its 275" maximum lift height and 57" turning radius support efficient operation in standard storage aisles.

Distribution Center Operations

In distribution centers requiring high-volume, repetitive picks across multiple racking levels, the lithium battery and AC drive system support sustained operation with minimal interruption for charging or maintenance.

Manufacturing Floor Storage

The EOP150 navigates manufacturing floor storage systems where components, sub-assemblies, or finished goods are stored at height, providing operators access up to 275" without requiring separate elevated access equipment.

Racking and Storage Facility Retrieval

With a fork lowered height of 2.2" and a cabin ground clearance of 87", the machine is designed to access standard racking systems and retrieve loads up to 1,500 lbs across the range of heights found in commercial storage facilities.

Compatible Materials

• Smooth concrete warehouse and distribution center floors
• Standard pallet loads up to 1,500 lbs (1000×1200 mm and 800×1200 mm pallet formats supported)
• Racking systems with pick heights up to 275"

Frequently Asked Questions

Q: What lift height options are available for the EOP150 Series?
A: The EOP150 Series is available in three lift height configurations: 165" (EOP150-165LI), 216" (EOP150-216LI), and 275" (EOP150-275).

Q: What type of battery does the EOP150 use?
A: The EOP150 Series uses a 24V / 200Ah lithium battery with a hoist-lift replacement method, distinguishing it from lead-acid-powered alternatives in the EKKO lineup.

Q: What is the minimum aisle width required for the EOP150?
A: The EOP150 requires 114" of aisle width for 1000×1200 mm pallets and 118" for 800×1200 mm pallets.

Q: What controller does the EOP150 use?
A: The EOP150 Series uses a Curtis® controller paired with an AC drive motor for reliable, precise performance management.

Q: What is the maximum load capacity of the EOP150?
A: The EOP150 Series has a rated load capacity of 1,500 lbs.
