20-Gallon Single Stage Electric Air Compressor is a versatility of the 20-gallon air compressor offers extra air storage and comes in stationary or portable models

This single stage 20 gallon electric air compressor features a powerful and efficient two stage compressor designed to maximize productivity. The versatility of the 20-gallon air compressor offers extra air storage and comes in stationary or portable models

Compressor Pump: Splash lubricated · Stainless-steel braided discharge hose · Large canister intake filter · Oil level sight indicator

Frame: Powder coated ASME coded 20-gallon receiver tank · 3/16-inch base plate to reduce vibration · 14-gauge powder coated two-piece belt guard

Components: Regulator and two gauges for tank and outlet pressure · Manual drain valves for proper maintenance · 16 1/2-inch fly wheel · Quality pilot valve unloader

*Equipped with 150-PSI maximum rated regulator

Specifications

  • CFM @ 175 PSI*

    17.2

  • Displacement/ Engine

    270cc Honda GX270 OHV

  • Compressor

    Two Stage, Cast Iron

  • Tank Size

    20 gallon

  • Engine Idle Control

    Pneumatic

Weights & Dimensions

  • Net Weight

    306.00 lbs.

  • Shipping Weight

    356.00 lbs.

  • Length

    37.00 in.

  • Width

    18.00 in.

  • Height

    38.00 in.

Options

  • AX-0003 Manual Drain/Regulator/Metal Bowl

    Drains moisture from air system

  • AX-0015 Electric Start - Battery and Cables Not Included

    For easy starting

  • IX-0055 Remote Start/Choke

    Remote start/choke; 6-foot wire extension for key switch; you will also need to order electric start option, AX-0015

  • IX-0059 Remote Start/Choke

    Remote start/choke; 6-foot wire extension for key switch, sealed cable; you will also need to order electric start option, AX-0015

  • AX-0017 Electric Start - Battery and Cables Included

    For easy starting
